Anatomy of a Landslide

Anatomy09

Drill rigs drilling test borings to gather more data. June 2000.

Anatomy10

Design specifications for the repair are complete. Stitch beams arrive on site. December 2000.

Anatomy11

Stitch beams tie back connection points.

Anatomy12

Installing stitch beams along the back side of Silver Ridge Court, above the slide area. December 2000.

Anatomy13

Concrete poured into place around the stitch beams. January 2001.

Anatomy14

Installing tie-backs through the stitch pilings. January 2001.

Anatomy15

Lateral drill rig for installing tie-backs. January 2001.

Anatomy16

Tie-backs are complete and ready to cover. January 2001.
