Anatomy of a Landslide

Anatomy17

Connecting all the stitch beams and tie-backs into one collective structure using a bond beam. January 2001.

Anatomy18

Completed concrete bond beam. Late January 2001.

Anatomy19

With hillside now secured, begin grading work to dress the top of the Bond beams. February 2001.

Anatomy20

Finish grading around bond beams is completed and covered with protective jutt netting. February 2001.

Anatomy21

Another view of finish grading around bonds beams. February 2001.

Anatomy22

Waiting for the opportunity to grade out the slides loose debris. April 2001.

Anatomy23

Grading begins. Removal and recompaction of loose landslide materials. May 2001.

Anatomy24

Another view of grading operations. May 2001.
